1976 Frigidaire Washers, Dryers and Laundry Centers Brochures


Published by Frigidaire in 1976-- Here are some beautiful brochures highlighting the 1976 line of Frigidaire Automatic Washers, Dryers and stacked Skinny-Mini Laundry Centers.

Full images and specifications included. Models include...

Washers: WIC, WID, WCD, WCDA, WL, WA.
Dryers: DE, DG, DEC, DEG, DEI, DGI, DECI and DGCI.
Laundry Centers: LC-115 and LC-3.

Also included in the 1976 brochure is the very rare model budget model WA. This is a 1/18 style washer, with a timed fill and 1960's style Deep Action Agitator. Appended at the end is the Tech-Tips introducing the new budget model with full views of the control panel, washer tub and agitator and cycle charts.

This brochure is rare and it's scanned at super high-resolution of 600dpi for crisper close-ups/zooms.

Number of Pages: 19
File Size: 56mb
Download Fee: $7.99

  Add 1976 Frigidaire Washers, Dryers and Laundry Centers Brochures to cart
