Page 1:Frigidaire 30" Ranges.
You'll be proud to add their elegant styling and innovative conveniences to your kitchen.
Page 2:
Top to bottom, Frigidaire 30" Ranges offer plenty of cooking flexibility, and cleaning ease.
With Frigidaire Touch-N-Cook Ranges, easy computerlike cooking is just a touch of the finger away. Whether you're baking, broiling, roasting or surface cooking, the revolutionary Touch-N-Cook Ranges follow your touched-in instructions on its solid state control panel with precision and accuracy. With the mere touch of your fingertip, you can program either model to begin cooking at a specified time and temperature. The Touch-N-Cook oven even changes its setting, automatically, to a holding temperature once cooking time has elapsed to keep your dinner warm until you're ready to serve it.
The Frigidaire Electri-clean Oven eliminates old-fashioned hand oveo cleaning; (leaves the oven, and drip bowls sparkling clean.)
Frigidaire takes the drudgery out of oven cleaning two easy ways. Self-cleaning Frigidaire Electri-clean models put an end to the messiest chore in kitchen: scrubbing and scouring the oven with costly cleaning agents. Crusty, baked-on food spatters are reduced to a mere trace of ash that wipes right out. You'll be surprised at how remarkably clean your oven gets . . . using only pennies of electricity!
Two Frigidaire 30" Ranges offer continuous-cleaning back and side panels that start making themselves presentably clean during normal baking and roasting. All panels, including a porcelain enamel bottom panel, slide out easily for sink-side cleaning when there's extra heavy soil.
RG-35 Cookmaster
RC-30 Continuous Cleaning
RGC-35 Continuous Cleaning with Cookmaster
Count on the Frigidaire Automatic Cookmaster to keep meals on schedule, even when the cook's away. With the Cookmaster, featured on most models, you can program your Frigidaire Range to start baking or roasting automatically at a preselected time and temperature, then automatically turn off the oven when time's up.
Inside every Frigidaire 23"-wide oven, enough room to bake as many as 6 pies or cakes at once. Besides delivering a full measure of baking space, every Frigidaire Range is equipped with two oven racks, adjustable to five different positions for more flexibility.
R-30 Conventional
RE-36 Electri-Clean
Page 3:
RE-38S Electri-Clean
REG-38 Glass Door Electri-Clean
R- 30 R6- 35 RC- 30 RGC- 35 RE- 36 RE- 388 REG- 38 REG- 380 REG- 380 REG- 3900
COOKING CONVENIENCES
Touch-N-Cook Controls
Easy-View Infinitely Adjustable Surface Unit Controls
Ceramatop Cooking Surface
6" Surface Heating Units (Areas)
8" Surface Heating Units (Areas)
Heat Minder Surface Unit
Surface Unit Signal Light
Hot Surface Signal Light
Console Light
Cookmaster Oven Controls
Clock
Minute Timer
Automatic Oven Preheat
Broiler-Roaster Pan
Window in Standard Door
Window in Black Glass Door
Rotisserie Provision
Full-Width Storage Drawer
CLEANING CONVENIENCES
Spill-Saver Top
Electri-clean Oven
Continuous-cleaning Oven Panels
Lift-Off Oven Door
Self-Cleaning Broiler Shield
ACCESSORIES
Rotisserie Kit (9956983)
Designer Door Kit RFK-31
Spatter-Free Broiler Grill (6561567
Kant-Slide Grille (9952086)
COLOR SELECTION!
Almond
Avocado
Coffee
Terra Cotta
Wheat
Snowcrest White Available all models
Exclusive Frigidaire Radiantube surface units provide good contact with cookware, good use of energy. Because they're wide and flat, Frigidaire Radiantube surface units provide positive contact with flat-bottomed pots and pans and help assure uniform cooking results at any temperature. To make the most of energy, their unique V-shaped design helps radiate heat upward to the cooking utensil where it belongs.
From Frigidaire, beauty with a practical purpose. With Frigidaire Ceramatop Ranges, you'll enjoy the beauty of an elegant, smooth ceramic cooking surface with no drip bowls or exposed surface units to trap grease and dirt. What's more, no special cookware is required with this durable top.
REG-38C Ceramatop
REG-380 Touch-N-Cook
Page 4:
There's more to Frigidaire styling than simply elegance. Behind the appealing black glass door panels on four models is a see-through window that lets you check on cooking progress without opening the door.
Your creativity doesn't have to end with your cooking. On solid-door models, you can make the Frigidaire Range part of the decor. All it takes is a Designer Door Kit (available at extra charge), and almost any decorator material like cork, tile or wallpaper (up to 3 1/2" thick), and a few tools.
Kant-Slide Griddle. Stays put on any 8-inch Radiantube surface unit. Durable Silver-Stone finished aluminum is easy to clean. Great for eggs and pancakes or steaks. DuPont's registered trademark for this premium non-stick finish.
Spatter-Free Broiler Grill helps prevent grease drippings from spattering on the oven walls.
Rotisserie Kit slowly and automatically turns a roast or fowl, basting the meat in its own natural juices.
Frigidaire 30" Range Warranties. Full One-Year Warranty, for the repair of any defect or malfunction in the entire Range.
For Touch-N-Cook Ranges:
Full One-Year Warranty, for the repair of any defect or malfunction in the entire Touch-N-Cook Range. Plus, a Limited Warranty on any defective or malfunctioning part in the Circuit Board. During the Limited Warranty consumer will be responsible for all labor costs. Backed by General Motors Corporation. See your Frigidaire Dealer for details.
SPECIFICATIONS R-30 RG- 35 RC- 30 RGC- 35 RE- 36 RE- 388 REG- 38 REG- 380 REG- 380 REG- 39CD
EXTERIOR DIMENSIONS
A. Width overall
B. Height overall
C. Height to cooking surface
D. Depth overall
Oven Interior Width (Inches)
Connected Load* (kW) @ 236V @ 208V
3-Wire Power Supply Cord attached at factory
Uncrated Weight (approx lb)
Shipping Weight (approx lb)
"Most models operate on 120/208 V or 120/240 V (Models REG-38C, REG-38D, and REG-39CD operate on 120/240 V only), 3-wire 1-phase, 60 Hz.
Listed by Underwriters' Laboratories, Inc.
Accessories
You'll be as proud to own Frigidaire appliances as we are to build them.
Page 5:
Frigidaire Twin 30 Ranges.
They offer elegant, double-oven convenience you'll be proud to add to your kitchen.
Page 6:
In a space just 30" wide, it's easy to install the double-oven cooking capacity and cleaning convenience of a Frigidaire Twin 30 Range.
Exclusive Frigidaire Radiantube surface units provide good contact with cookware, good use of energy. Because they're wide and flat Frigidaire Radiantube surface units on Model REG-637V provide positive contact with flat-bottomed pots and pans and help assure uniform cooking results at any temperature. To make the most of energy, their unique V-shaped design helps radiate heat upward to the cooking utensil where it belongs.
The Frigidaire Electri-clean Oven eliminates old-fashioned hand oven-cleaning.
With Frigidaire, you don't have to use a lot of electricity to save a lot of time. Thanks to the Electri-clean lower oven in both Frigidaire Twin 30 models, you can put an end to the messiest and most time-consuming chore in the kitchen: scrubbing and scouring the oven. Crusty baked-on food spatters are reduced to a mere trace of ash that wipes right out... for just pennies each cleaning cycle!
For the double oven cleaning convenience of Electri-clean Plus, just remove the panels from the upper oven of Model REG-639CV, and clean them in the lower Electri-clean Oven, automatically.
From Frigidaire, beauty with a practical purpose: easier cleaning. With the Frigidaire Ceramatop Twin 30 Range, you'll enjoy the beauty of an elegant, smooth ceramic cooking surface with no drip bowls or exposed surface units to trap grease and dirt.
You'll be able to use most of your own favorite flat-bottomed pats and pans, too, because no special cookware is required with the durable Ceramatop material.
Count on the Frigidaire Cookmaster to keep meals on schedule, even when the cook is away. With the Cookmaster, you can program your Frigidaire Twin 30 Range to start baking or roasting automatically at a preselected time and temperature, then automatically turn off the oven when time's up.
Rare of Well-done: Frigidaire gives you a choice when you're broiling meats. The
Broiler Grill control on model REG-639CV takes the guesswork out of broiling steaks or chops. Simply dial the degree of doneness you prefer: Rare, Medium Rare, Medium, Medium Well, or Well.
To guard against scorching and boil overs, count on the Frigidaire "pot watcher." The
Heat Minder feature is a sensing device in the center of the right front surface unit of Model REG-637V that automatically regulates the temperature of a pot or pan, keeping it at the setting you selected.
Page 7:
REG-637V
REG-639CV
COOKING CONVENIENCES
Easy-View Surface Unit Controls
Yes
Infinitely Adjustable Surface Unit Controls
Yes
Yes
Ceramatop Cooking Surface
Yes
6" Surface Heating Units (areas)
8" Surface Heating Units (areas)
Heat Minder Surface Unit
R.F.
Surface Unit Signal Light
Yes
Hot Surface Signal Light
Yes
Cooktop Light
Yes
Yes
Cookmaster Oven Controls
Lower
Either
Clock and Minute Timer
Yes
Yes
Signal-Dial Oven Temperature Controls
Oven Signal Light
Both
Both
Broiler Grill Control
Lower
Broiler-Roaster Pan
Lower
Both
Full-width Window Door
Upper
Upper
Window in Black Glass Door
Lower
Lower
Interior Oven Lights
Both
Both
Full-Width Storage Drawer
Yes
Yes
CLEANING CONVENIENCES
Spill-Saver Top
Yes
Yes
Electri-clean Oven
Lower
Lower
Electri-clean Plus (removable panels)
Upper
Built-in Power Exhaust fan (2 speed)5'
Yes
Yes
Porcelain Enamel Oven Liner
Both
Both
Self-Cleaning Broiler Shield
Both
Both
ACCESSORIES
Spatter-Free Broiler Grill (6561567)
Kant-Slide Griddle (9952086)
Rotisserie Kit (9956983), lower oven
Inside Triple Filtering Vent Kit (6597612)
COLOR SELECTION
Almond
Avocado
Coffee
Terra Cotta
Wheat
Snowcrest White
May be vented to the outside.
Available at extra charge. Both models are equipped with a black glass lower oven door and a patterned black glass upper oven door.
The models pictured may not be shown in available colors.
Page 8:
Accessories
There's more to Frigidaire styling than simply elegance. Behind the appealing black glass lower oven door is a see-through window that lets you check on cooking progress without opening the door.
Kant-Slide Griddle. Stays put on any 8-inch Radiantube surface unit. Durable Silver-Stone* finished aluminum is easy to clean. Great for eggs and pancakes or steaks. •DuPont's registered trademark for this premium non-stick finish.
Spatter-Free Broiler Grill helps prevent grease drippings from spattering on the oven walls.
You get a feeling of security from the Frigidaire Twin 30 Range Full One-Year Warranty,
for the repair of any defect or malfunction in the entire Range. Backed by General Motors Corporation. See your Frigidaire Dealer for details.
Rotisserie Kit slowly and automatically turns a roast or fowl, so that it bastes in its own natural juices.
Frigidaire Twin 30 Ranges can turn your kitchen into a more pleasant environment.
Frigidaire engineers have designed an effective built-in Power Exhaust Fan that pulls cooking odors and smoke directly out of your kitchen to an outside vent. If inside venting is desired, an effective Triple Filtering Kit is available at extra charge.
SPECIFICATIONS REG-637V REG-639CV
Oven Interior Widths (upper, lower) (inches)
Connected load (kW) @ 236V & 208V
3-Wire Power Supply Cord attached at factory
Uncrated Weight approx lb
Shipping Weight approx lb
Model REG-637V operates on 120/208 or 120/240 volt, 1 phase, 60 Hz. REG-639V operates on 120/240V only.
Listed by Underwriters' Laboratories, Inc.
You'll be as proud to own Frigidaire appliances as we are to build them.
Page 9:
Frigidaire 40" Ranges.
They offer a lot you'll be proud to own: cooking conveniences, spacious storage and extra workspace.
RE-47
Double Oven
Page 10:
For an extra measure of
kitchen convenience,
choose any Frigidaire 40" Range.
With Frigidaire, you don't have to use a lot of energy to save a lot of time. The
self-cleaning Frigidaire Electri-clean models-RE-45 and RE-47-put an end to the messiest and most time-consuming chore in the kitchen: scrubbing and scouring the oven, oven racks and drip bowls. Crusty, baked-on food spatters are reduced to a mere trace of ash that wipes right out. You'll be surprised how little it costs to operate, too-just pennies each cleaning cycle!
For extra oven cleaning convenience we call Electri-clean Plus, just remove the panels from the smaller oven of Model RE-47, and clean them in the larger Electri-clean Oven, automatically.
Another easy way to save time and effort: bake and clean at the same time.
If you prefer an oven with the continuous cleaning feature select the Frigidaire 40" Range with continuous-cleaning back and side panels that start cleaning themselves of ordinary food spatters during normal baking and roasting.
Frigidaire gives you a choice: an extra oven or extra storage space. Choose our double oven model, and get extra oven capacity plus the flexibility to bake pecan pie in one oven while you roast a large turkey in the other.
Count on the Frigidaire Cookmaster to keep meals on schedule, even when the cook's away. With the Cookmaster, you can program your Frigidaire Range to start baking or roasting automatically at a preselected time and temperature, then automatically turn off the oven when time's up. A real convenience when you can't be home just before dinner or supper.
Instead of an extra oven, our other 40" models offer a pull-out drawer for waist-level storage of pots, pans and other cooking utensils.
Whichever model you select, it features a full-width storage drawer underneath. Up above, a porcelain enamel workspace top with the Spill-Saver feature to help keep accidental spills on top for easy clean up.
RE-45 Electri-Clean
Frigidaire 40" Range Full One-Year Warranty, for the repair of any defect or malfunction in the entire range. Backed by General Motors Corporation. See your Frigidaire Dealer for details.
COOKING CONVENIENCES RGC-45 RE-45 RE-47
Easy-View Infinitely Adjustable Surface Unit Controls
6" Radiantube Surface Heating Units
8" Radiantube Surface Heating Units
Heat Minder Surface Unit
Surface Unit Signal Light
Console Light
Two Ovens
Cookmaster Oven Controls
Clock and Minute Timer
Oven Signal Light
Broiler Grill Control
Window in Door
Interior Oven Light(s)
Waist-High Storage Drawer
Full-Width Storage Drawer
Broiler-Roaster Pan
CLEANING CONVENIENCES
Spill-Saver Top
Electri-clean Oven
Electri-clean Plus
Continuous-cleaning Oven Panels
Lift-Off Oven Door
Porcelain Enamel Oven Liner(s)
Self-Cleaning Broiler Shield(s)
ACCESSORIES
Radiant Wall Spatter-Free Broiler Grill (6561567)
Kant-Slide Griddle (9952086)
Rotisserie Kit (9956984)
COLOR SELECTION*
Almond
Avocado I
Wheat
Snowcrest White
SPECIFICATIONS
Oven Interior Widths (left, right) (inches) 167/s 17 16%, 17
Connected Load* (kW) @ 236V 12.7 12.7 15.7
@ 208V 10.1 10.1 12.4
3-wire Power Supply Cord attached at factory Yes Yes Yes
Uncrated Weight approx lb 229 242 295
Shipping Weight approx lb 270 278 335
* All models operate on 120/208V, 3-wire, 1-phase, 60 Hz. ^"Available at extra charge.
Listed by Underwriters' Laboratories, Inc. tThe models pictured may not be shown in available colors.
You'll be as proud to own Frigidaire appliances as we are to build them.
Frigidaire - Why settle for less?
Page 11:
Frigidaire Microwave Ovens fit where they're needed: on a counter or right in the wall.
Thanks to a built-in kit, available for RCM-5, RCM-7, and RCM-9, you can install the convenience of microwave cooking in the wall if counterspace is limited. The kit allows clearances and venting for proper air circulation.
Frigidaire takes the mystery out of microwave cooking, at no extra charge. To make microwave cooking easier than ever, Frigidaire provides hundreds of time-saving ideas and kitchen-tested recipes with every microwave oven.
Accessories
(available at extra charge)
RCM-1 RCM-3 RCM-5 RCM-7 RWM-7 RCM-9
Watts: Input/Output
Dimensions
A Exterior Height
B Exterior width w/door closed
C Exterior width w/door full open
D Exterior depth w/door closed
E Exterior depth w/door open 90°
F Oven width
G Oven depth
H Oven height
Cutout dimensions for built-in installation
Height
Width
Depth
Uncrated Weight (Approx lb)
Shipping Weight (Approx lb)
Built-in installation only
All models operate on 115-volt, 60-Hz, 3-wire separate grounded circuit. Listed by UL Inc and CSA.
Frigidaire Browning Skillet adds beautiful browning to instant cooking.
Portable cart makes it easy to move a Frigidaire Microwave Oven from room to room; provides three-shelf storage convenience.
Non metallic Roasting Rack. Fits standard Pyrex® roasting dish. Dishwasher safe.
Microwave Oven Cooking Thermometer. Use
it during microwave time for cooking meats, poultry, and other foods. Has a range of 0° to 220° F.
Frigidaire Microwave Oven Full One-Year Warranty, for the repair of any defect or malfunction in the entire Microwave Oven. Plus, a Limited Warranty on any defect or malfunctioning Magnetron Tube. During the Limited Warranty consumer will be responsible for all labor costs. Backed by General Motors Corporation. See your Frigidaire Dealer for details.
RCM-1
RCM-3
RCM-5
RWM-7
ADD RETAINER BRACKETS BEHIND LOWER TRIM AT RIGHT & LEFT SIDE BEFORE INSTALLING ABOVE WALL OVEN.
You'll be as proud to own Frigidaire appliances as we are to build them.
Page 12:
Frigidaire Wall Ovens.
You'll be as proud of their cooking and cleaning conveniences as you are of their elegant styling.
Page 13:
RE-94 Electri-Clean
Add an extra touch of elegance to your kitchen when you build in the cooking and cleaning conveniences of a Frigidaire Wall Oven.
With Frigidaire Touch-N-Cook Walt Ovens, easy computerlike cooking is just a touch of the finger away. Whether you're baking, broiling, or roasting, the revolutionary Touch-N-Cook Wall Ovens follow your touched-in instructions on its solid state control panel with precision and accuracy. With the mere touch of your fingertip, you can program it to begin cooking at a specified time and temperature. To keep dinner warm until you're ready to serve it, the Touch-N-Cook oven automatically changes its setting to a holding temperature once cooking time has elapsed.
The Frigidaire Electri-clean Oven eliminates old-fashioned hand oven cleaning. (Shown with porcelain enamel drip bowls.)
Frigidaire takes the drudgery out of oven cleaning. Self-cleaning Frigidaire Electri-clean models put an end to the messiest chore in the kitchen: scrubbing and scouring the oven with costly cleaning agents. Crusty, baked-on food spatters are reduced to a mere trace of ash that wipes right out. You'll be surprised how little it costs to operate, too!
With one continuous-cleaning oven model, normal oven soil on specifically treated side and back panels is gradually reduced to a presentably clean condition during normal baking and roasting. Of course, heavy spillovers must be wiped off the panels; the untreated bottom panel and door must be cleaned by hand.
RG-94 Conventional
Count on the Frigidaire Automatic Cookmaster to keep meals on schedule, even when the cook's away. With the Cookmaster, you can program your Frigidaire Wall Oven to start baking or roasting automatically at a preselected time and temperature, then automatically turn off the oven when the time's up.
RC-97 BK Continuous Cleaning
REG-94 BK Electrl-Clean
RE-94D Touch-N-Cook
Page 14:
RE-97 Electrl-Clean
REG-97 BK Electri-Clean
RG- 94 RC-97 BK RE- 94 REG-94 BK RE- 97 REG-97 BK RE- 940 REG-940 BK
COOKING CONVENIENCES
Two Ovens
Touch-N-Cook Control
Display Window
Cook-Master Oven Control
Clock and Minute Timer
Automatic Oven Preheat
Oven Light
Oven Signal Light
Control Panel Light
Glass Window in Door
Interior Oven Light(s)
Broiler-Roaster Pan
Radiantube Heating Units
CLEANING CONVENIENCES
Electri-clean Oven
Continuous-cleaning Panels
Drop-Leaf Door
Porcelain Enamel Exteriorf
Porcelain Enamel Interior(s)
ACCESSORIES
Radiant Wall Spatter-Free Broiler Grill (6561567)
COLOR SELECTION*
Almond
Avocado
Black Glass
Brushed chrome
Coffee
Terra Cotta
Wheat
Snowcrest White
Available at extra charge.
Except models in black glass or brushed chrome finish.
The models pictured may not be shown in available colors.
Double the cooking convenience with Frigidaire double oven models. Separate controls let you bake a chocolate cake in one oven while you broil steak in the other. With the added flexibility of a Frigidaire double oven model, you can spend less time juggling cooking schedules, and even handle big-size family meals with room to spare.
Inside each oven, you'll find adjustable shelves that make it easy to tailor the space to the items you're cooking.
Both ovens of model RC-97 BK offers removable continuous-cleaning panels.
Page 15:
SPECIFICATIONS RG- 94 HC-97 BK RE- 94 REG-94 BK RE- 97 REG-97 BK RE- 940 REG-940 BK
Oven Interior Width(s) Upper, Lower (inches)
Connected Load* (kW) @ 236V. @ 208V.
Uncrated Weight (Approx Lb)
Shipping Weight (Approx Lb)
DIMENSIONS
A Height of Wall Oven
B Width of Wall Oven
C Depth of Wall Oven
D Height of opening (min)
E Width of opening (min)
F Depth of opening
All models operate on 120/240 V, 3-wire, 1 Listed by Underwriters' Lab, Inc.
phase, 60 Hz. All except RE-94D and REG- armored cable included.
94D BK also operate on 120/208V.
Accessories
Spatter-Free Broiler Grill helps prevent grease drippings from spattering on the oven walls.
Frigidaire Wall Oven Full One-Year Warranty,
for the repair of any defect or malfunction in the entire Wall Oven.
For Touch-N-Cook Wall Ovens. Full One-Year Warranty, for the repair of any defect or malfunction in the entire Touch-N-Cook Wall Oven. Plus, a Limited Warranty on any defective or malfunctioning part in the Circuit Board. During the Limited Warranty, consumer will be responsible for all labor costs. Backed by General Motors Corporation. See your Frigidaire dealer for details.
You'll be as proud to own Frigidaire appliances as we are to build them.
Page 16:
Frigidaire Cooking Tops. Their built-in cooking and cleaning conveniences will be a proud addition to your kitchen.
Page 17:
Top off your counter with a Frigidaire Cooking Top: it's a beautiful way to build in plenty of cooking and cleaning convenience.
Easy, accurate cooking: it's just a touch of your finger away. Our revolutionary Frigidaire Touch-N-Cook Cooking Top with solid-state circuitry follows your touched-in surface cooking instructions with computer like accuracy. For easy, convenient cleaning the smooth glass control panel is free from obstructions that can trap crumbs and spills.
Exclusive Frigidaire Radiantube surface units provide good contact with cookware, good use of energy. Because they're wide and flat, Frigidaire Radiantube surface units provide positive contact with flat-bottomed pots and pans and help assure uniform cooking results at any temperature. To make the most of energy, their unique V-shaped design helps radiate heat upward to the cooking utensil where it belongs.
From Frigidaire, beauty with a practical purpose. With our two top-of-the-line Frigidaire Cooking Tops-RB-137C and RB-139D, you'll enjoy the beauty of an elegant, smooth ceramic cooking surface with no drip bowls or traditional surface units to trap grease and dirt.
You'll like being able to use most of your own favorite flat-bottomed pots and pans, too, because no special cookware is required.
To guard against boilovers, count on the Frigidaire "pot watcher." Our Heat Minder feature is a sensing device in the center of the right front surface unit that automatically regulates the temperature of a pot or pan, keeping it at the setting you selected. The Frigidaire Heat Minder: a real convenience, available when you choose Model RB-133.
RB-131 RB-133 RB-137C RB-139D
COOKING CONVENIENCES
Ceramatop Cooking Surface
Touch-N-Cook Controls
Touch Control Digital Clock and Display Window
Automatic Timer
6" Surface Heating Units (Areas)
8" Surface Heating Units (Areas)
Heat Minder 8" Heating Unit
Infinitely Adjustable Surface Unit Controls
Easy-View Surface Unit Controls
Surface Unit Signal Light
Hot Surface Signal Light
CLEANING CONVENIENCES
Spill-Saver Top
Aluminum Drip Bowls
Easy-Clean Control Panel
Pull-off Control Knobs
ACCESSORIES
Kant-Slide Griddle (9952086)
Flush-mounting Trim Ring (6590436)
COLOR SELECTION
Almond
Brushed Chrome
Coffee
Terra Cotta
Wheat
Snowcrest White
Available at extra charge
The models pictured may not be shown in available colors.
Page 19:
From Frigidaire, a smooth, contemporary solution to the problems of cleaning. Frigidaire Cooking Tops can be mounted flush to the countertop to give you a contemporary look that also makes cleaning easier. Ceramatop models RB-137C and RB-139D are designed for standard flush mounting. A trim ring, available at extra charge, lets you install models RB-131 and RB-133 flush to the countertop.
SPECIFICATIONS RB-131 RB-133 RB-137C RB-139D
Connected Load* (kW) @ 236 V
@ 208 V
Uncrated weight (approx lb)
Shipping weight (approx lb)
DIMENSIONS (Inches)
A Width of cooking top
B Depth of cooking top
C Height of cooking top
D Width of opening
E Depth of opening
F Minimum counter height
Frigidaire Cooking Top Full One-Year Warranty, for the repair of any defect of malfunction in the entire Cooking Top.
Touch-N-Cook model: Full One-Year Warranty, for the repair of any defect or malfunction in the entire Cooking Top. Plus, a Limited Warranty on any defective or malfunctioning part in the Circuit Board. During the Limited Warranty consumer will be responsible for all labor costs. Backed by General Motors Corporation. See your Frigidaire Dealer for details.
All models operate on 120/240 V, 3-wire, 1 phase, 60 Hz. Models RB-131 and RB-133 also operate on 120/208 V.
Listed by Underwriter's Laboratories, Inc.
Install a Frigidaire Cooking Top just about anywhere. Shallow-depth design of two Frigidaire Cooking Top models-RB-131 and RB-133-lets you build them in where counter depth is limited, even over a shallow drawer.
Accessories
Kant-Slide Griddle. Stays put on any 8-inch Radiantube surface unit. Durable Silver-Stone* finished aluminum is easy to clean. Great for eggs and pancakes or steaks. *DuPont's registered trademark for this premium non-stick finish.
You'll be as proud to own Frigidaire appliances as we are to build them.
Page 20:
Frigidaire Compact 30 Ranges. They're designed for maximum cooking and cleaning convenience, and styled with elegance you'll be proud to build in.
Page 21:
Frigidaire Compact 30 Ranges offer built-in cooking innovations and cleaning conveniences.
With the Frigidaire Touch-N-Cook Range, easy computerlike cooking is just a touch of the finger away. Whether you're baking, broiling, roasting or surface cooking, the revolutionary Touch-N-Cook Compact 30 follows your touched-in instructions on its solid-state control panel with precision and accuracy. With the mere touch of your fingertip, you can program it to begin cooking at a specified time and temperature. Our Touch-N-Cook oven even changes its setting, automatically, to a holding temperature once cooking time has elapsed to keep a roast warm until you're ready to serve it.
Count on the Frigidaire Automatic Cookmaster to keep meals on schedule, even when the cook's away. With the Cookmaster, featured on every model except R-530, you can program your Frigidaire Range to start baking or roasting automatically at a preselected time and temperature, then automatically turn off the oven when time's up.
The Frigidaire Electri-clean Oven eliminates old-fashioned hand oven cleaning. (Shown with porcelain enamel drip bowls.)
Frigidaire takes the drudgery out of oven cleaning. Self-cleaning Frigidaire Electri-clean models put an end to the messiest chore in the kitchen: scrubbing and scouring the oven with costly cleaning agents. Crusty, baked-on food spatters are reduced to a mere trace of ash that wipes right out. You'll be surprised how thoroughly it cleans . . . using only pennies of electricity!
For a different kind of cleaning convenience, select a Frigidaire Compact 30 Range with continuous-cleaning back and side panels that start making themselves presentably clean during normal baking and roasting. All panels, including a porcelain bottom panel, slide out easily for sink-side cleaning when there's extra heavy soil.
Inside every Frigidaire 23"-wide oven, enough room to bake as many as 6 pies or cakes at once. Besides delivering a full measure of baking space, every Frigidaire Range is equipped with two oven racks, adjustable to five different positions for more flexibility.
R-530 Conventional
RG-533 Cookmaster
RGC-533 Continuous Cleaning
Page 22:
RE-533 Electri-Clean
REG-533CH Electri-Clean
RE-537 Electri-Clean Full Console
REG-539C Ceramatop
R- 530 AG- 533 RGC- 533 RE- 533 RE6- 533CH RE- 537 REG- 539C REG- 539CD
COOKING CONVENIENCES
Touch-N-Cook Controls
Ceramatop Cooking Surface
Infinitely Adjustable Surface Unit Controls
Easy-View Surface Controls
6" Surface Heating Units^Areas)
8" Surface Heating Units (Areas)
Surface Unit Indicator Light
Hot Surface Signal Light
Glass-covered Control Panel
Cookmaster Oven Controls
Clock and Minute Timer
Automatic Oven Preheat
Window in Porcelain Enamel Door
Window in Black Glass Door
Broiler-Roaster Pan
CLEANING CONVENIENCES
Pull-off Control Knobs
Spill-Saver Top
Electri-clean Oven
Continous-cleaning oven panels
Lift-off Oven Door
Self-cleaning Broiler Shield
ACCESSORIES
Rotisserie Kit (9956983)
Radiant Wall Spatter-Free Broiler Grill (6561567)
Kant-Slide Griddle (9952086)
Back Panel Kit (BP-30)
Designer Door Kit (RFK-31)
COLOR SELECTIONS $
Almond
Avocado
Coffee
Terra Cotta
Wheat
Snowcrest White
Black glass door panel
Available at extra charge.
Model REG-533CH comes with Brushed Chrome top.
The models pictured may not be shown in available colors.
Exclusive Frigidaire Radiantube surface units promote good contact with cookware, good use of energy. Because they're wide and flat, Frigidaire Radiantube surface units provide positive contact with flat-bottomed pots and pans and help assure uniform cooking results at any temperature. To make the most of energy, their unique V-shaped design helps radiate heat upward to the cooking utensil where you want it.
From Frigidaire, beauty with a practical purpose. With the Frigidaire Ceramatop and Touch-N-Cook Compact 30 Ranges, you'll enjoy the beauty of an elegant, smooth ceramic cooking surface with no drip bowls or exposed surface units to trap grease and dirt. What's more, no special cookware is required with this durable material.
Page 23:
There's more to Frigidaire styling than simply elegance. Behind the appealing black glass door panels on five models is a see-through window that lets you check on cooking progress without opening the door.
Frigidaire makes it easy to install cooking convenience in a kitchen. With models R-530, RG-533, RGC-533, RE-533 and REG-533CH you need only tour screws to hold the range firmly in place, once cutouts and electrical connections are complete. Adjustable front corner end caps hide minor cutout imperfections. Finishing off a between-cabinet installation is easy too, thanks to a Brushed Chrome back panel, (BP-30) available at extra charge.
The remaining 3 models-RE-537, REG-539C and REG-539CD-are even easier to install. For a clean, custom-installed look, easily adjusted control panel end caps help hide back panel cutout imperfections.
Frigidaire 30" Range Warranties give you peace of mind. Full One-Year Warranty, for
the repair of any defect or malfunction in the entire Range.
Full One-Year Warranty, for the repair of any defect or malfunction in the entire Touch-N-Cook Range. Plus, a Limited Warranty on any defective or malfunctioning part in the Circuit Board. During the Limited Warranty consumer will be responsible for all labor costs. Backed by General Motors Corporation. See your Frigidaire Dealer for details.
R- RG- RGC- RE- REG- RE- REG- REG-
SPECIFICATIONS
Oven Interior Width (Inches)
Connected Load" (kW) @ 236V
@ 208V
Uncrated weight (approx lb)
Shipping weight (approx lb)
* Most models operate on 120/240V or 120/208V (Models REG-539C and REG-539CD operate on 120/240V only), 3-wire, 1-phase, 60 Hz.48" armored cable included.
Your creativity doesn't have to end with your cooking. On solid-door models RE-533 and RE-537, you can make the Frigidaire Compact 30 Range part of the decor. All it takes is a Designer Door Kit (available at extra charge), and almost any decorator material like cork, tile or wallpaper (up to 3/16" thick), and a few tools.
R-530, RG-533, RGC-533, RE-533, REG-533CH
End plate - each adjusts laterally:
front of trim to back of control panel
Caution: depth of cabinet cutout is minus countertop thickness.
Product hangs from flange over countertop. Support under countertop at discretion of builder.
2" Recommended minimum countertop
Clearance req'd. for product trlm-typ. each side
RE-537, REG-539C, REG-539CD
minimum counter
Front of
Product hangs from flange counter top. Support under counter top at discretion of builder.
End caps adjust laterally
Bottom
of trim
BP-30 back panel for use when
range between cabinets, at extra charge)
cabinet cutout
*Add 1" for model RE-533, REG-533CH
to back of lead cover
You'll be as proud to own Frigidaire appliances as we are to build them.
Page 24:
Frigidaire Microwave Ovens. You'll be proud to add the convenience of fast, cool, clean cooking to your life.
Page 25:
Amazingly fast cooking is just one way a Frigidaire Microwave Oven can make your life easier.
In a matter of minutes, you can fix foods for breakfast, lunch or dinner with a Frigidaire Microwave Oven. From appetizers to desserts, you can cook many foods in up to 75% less time than it takes with a conventional range.
A 4-lb rib roast, medium, can be ready to serve in about 20 minutes, for example. Brown and serve rolls take just 20-25 seconds; corn-on-the-cob 4-6 minutes; a baked potato about the same time; and pineapple upside-down cake just 9 minutes.
From the freezer to the table in record time: that's microwave cooking from Frigidaire.
Frozen meats and casseroles can be ready to cook in a matter of minutes if you choose one of our microwave ovens with fast, automatic defrosting. Thaw a Cornish hen in less than 10 minutes; a pound of hamburger in 15 minutes; a 1-lb package of frozen fish filets in less than 10 minutes. Automatic defrosting: a convenience you'll particularly enjoy when unexpected guests drop in at dinner time or when you've forgotten to take dinner out of the freezer.
When you're in a hurry, Frigidaire adds time-saving convenience before the meal. When you're not rushed for time, make up large quantities of waffles, appetizers, casseroles and other dishes. Then freeze them in single meal containers for heating up later in your Frigidaire Microwave Oven when you're in a hurry.
Count on a Frigidaire Microwave Oven to help save energy and cooking costs. In addition to cooking in about 'A the time of conventional cooking, many foods can be cooked with 50 to 75% less energy. What's more, there's no energy wasted preheating the oven.
After-meal cleanup of messy pots and pans: it's cut down with a Frigidaire Microwave Oven. You'll often be able to mix, cook and serve in the same dish, reducing the number of pots, pans and other cookware to be washed.
In fact, with the exception of utensils and containers containing metal, there are few limitations to the type of cookware you can use. What's more, many frozen convenience foods can be cooked right in their containers or cooking bags, (after first puncturing them to allow steam to escape).
For your convenience, Frigidaire adds three microwave cooking speeds. Starting with Model RCM-5, you can select Low, Medium, or High microwave speed to match the foods you're cooking. To make it even easier to use your microwave oven, these three speeds correspond to the recipes in Frigidaire's Microwave Oven Cookbook, as well as other microwave cookbooks on the market.
Low is recommended for defrosting and simmering; Medium, for cooking certain meats and preparing cheese and egg dishes; High, for cooking most foods; frozen and fresh vegetables, bacon, fish, and beverages.
HIGH fast
REHEAT
MED
LOW - DEFROST
SOLID STATE COOK SELECTOR
From Frigidaire, the flexibility to tailor cooking speeds to different foods, different recipes. Our three top-of-the-line models feature an infinitely adjustable Cook Selector that lets you choose the proper speed for a variety of cooking chores: keeping foods warm, melting butter, simmering soups, roasting meats, reheating casseroles, and of course, ordinary cooking.
For fast microwave cooking with computer like accuracy, choose our Touch-N-Cook model. With the touch of a finger on the control panel, you can program Model RCM-9 to change its settings automatically. For example, once you've touched in instructions, it will remember how long to defrost, allow for "holding" time to assure even thawing throughout, then cook for the proper length of time, automatically.
Page 26:
RWM-7 (Built-In Model) RCM-1 (Free-Standing Model) RCM-3 (Free-Standing Model)
RCM-1 RCM-3 RCM-5 RCM-7 RWM-7 RCM-9
COOKING CONVENIENCES
Cook Selector
Oven interior light
Cycle-end signal
Cook Guide
See-thru door
Timer
Door swing
CYCLES
Variable speed Cook cycles, including defrost setting
Fast Cook
Slow Cook
Defrost
ACCESSORIES
Browning Skillet (9948305)
Roasting rack (9950003)
Portable cart (9949994)
Cooking Thermometer (9949993)
Built-In Kitf
FINISH, exterior
Model RWM-7 comes only with necessary framing materials for built-in installation. * Available at extra charge.
RWM-7 (Shown installed above a Frigidaire Electri-Clean Wall Oven, as a combination installation)
