Frigidaire Washer Tech-Talk Digest for 1950-1959 Models


Published by Frigidaire in 1959-- Here is an excellent reference guide for all 1950-1959 Frigidaire Unimatic, Pulsamatic and Multimatic Automatic Washers.

TECH-TALK DIGEST is a handy reference guide prepared for you, the Frigidaire Serviceman, as a source of information readily available on your service calls. It is designed as another aid in rendering prompt and efficient service on the customer's products.

This digest is made up of Automatic Washer information on 1950 models through 1959 models. Specifications, cycle of operation data, product illustrations, and wiring diagrams are included. It can be carried easily in your pocket or in the glove compartment of your car or truck.

Personal note pages are provided for you to use in entering items, such as Part Numbers, Service Tips, Serial Numbers, etc., which you want to keep for future reference.

We especially suggest that the Miscellaneous Section, Page 71, be carefully read and studied as it contains diagnosis and testing information applicable to all washer models.


Sections Include:
Capacitors-Checking by Wattage Method
Cutaway Drawings
Bellows Assembly, Pulsamatic Mechanism
Oil and Water Seal Bellows-Unimatic Mechanism
Mechanism, Pulsamatic
Cycle of Operation Tables
W0-65
W0-65-2
WV-35, 45, 65
WS, WD, WDS, WI-56
WI and WDU -57, WD, WSA, WS-57
WS, WD, WOP, WI, WCI, WCIR -58
WS, WD, WDR, WCD , WI, WCI, WCIR-59
Drain Screen-Removal on WV Washers
Electrical Test Procedures
Exploded Views, Mechanism
Pulsamatic
Three and Four Speed
Two Speed
Unimatic
Mechanism Applications-1959 Models
Mechanism Diagnosis and Improvements-
1959 Models
Motor Winding Resistance values-1959 Models
Nut and Seal Assembly-Improved on
1957 Unimatic Mechanisms
1957 Pulsamatic Mechanisms
Service Diagnosis-All Models
Service Replacements Without Moving
Washer-1959 Models
Snubber Plate
Clearance Check, Unimatic Mechanisms
Oil Check-Unimatic Mechanisms
Specifications
W0-65
W0-65-2
WV -35, 45, 65
WS, WD, WDS, WI -56
WS , WSA , WD, WDU , WI-57
WS, WD, WOP, WI, WCI, WCIR -58
WS , WD, WDR, WCD , WI, WCI , WCIR-59
SudsWater Saver Operational Diagram-WCIR -58
Switch, Lid-Operation Check on WI -58, WCI -58
Water Leaks-Suggestions for Correcting on
1958 Models
Water Pressure
Adapting Washers to Low Pressures
Timers for Low Pressures
Water Valves
Applications
Checking Inlet Screens
Repair, All Models
Tools
Wiring Diagrams
Wiring Schematics-Unimatic and Pulsamatic Mechanisms


Number of Pages: 104
File Size: 29mb
Download Fee: $7.99

  Add Frigidaire Washer Tech-Talk Digest for 1950-1959 Models to cart
